Integrated Photovoltaic Containerized Substation
1.Product Overview `
The Integrated Photovoltaic Containerized Substation is a cutting-edge, all-in-one solution designed to streamline solar energy generation, grid integration, and energy management. Combining photovoltaic (PV) arrays, smart inverters, and advanced containerized infrastructure, this system delivers scalable, efficient, and resilient power solutions for diverse applications—from remote off-grid installations to urban microgrids.
2.Product Features
1）Seamless Solar Integration: Optimized for large-scale PV farms, enabling high-voltage DC-to-AC conversion and grid synchronization.
2）Modular Design: Factory-prefabricated in 20/40ft containers for rapid deployment and minimal on-site construction.
3）Smart Energy Management: Embedded IoT sensors and AI-driven analytics for real-time monitoring of PV output, system efficiency, and grid stability
3. Operation environment
1) Altitude: ≤1000 meters.
2) Ambient temperature: Maximum +40oC, Minimum -45oC.
3) Relative humidity: ≤90% (+25 oC).
4) Max. Outdoor wind speed 45m/s;
5) Max Ground ramp degree: ≤3°.
6) Seismic level: ≤0.3m/s2 at horizontal direction and ≤0.15m/s2 at vertical direction.
7) Installation environment: No obvious and heavy pollution, no explosive and corrosive gas and dust, with good air ventilation and no severe vibration and shock.
8) If the application environment is different from the above standard conditions, please contact for customized designs.
4.Application Scenarios
1）Large-Scale Solar Farms: Grid-tied systems for utility-scale energy injection (e.g., 10 MW+ solar parks).
2）Remote Electrification: Off-grid mining sites, military bases, or disaster relief with hybrid PV-storage solutions
3）Urban Microgrids: Supports EV charging stations and peak-shaving in industrial parks
