Containerized Energy Storage Power Station
1.Product Overview `
The Containerized Energy Storage Power Station is a turnkey, scalable solution designed for efficient energy storage, grid stabilization, and renewable integration. Combining advanced battery systems, power conversion technology, and intelligent controls within a standardized container. This system enables rapid deployment for applications ranging from peak shaving and frequency regulation to off-grid microgrids and emergency backup power.
2.Product Features
1)Modular Design: Factory-prefabricated in 20/40ft containers for fast transportation, installation and capacity expansion.
2)Multi-Scenario Flexibility: Supports grid-tied, off-grid, and hybrid energy systems with AC/DC coupling options.
3)Smart Management: IoT-enabled monitoring with real-time data tracking (SOC, SOH, voltage, temperature) and SCADA/EMS integration.
3. Operation environment
1) Altitude: ≤1000 meters.
2) Ambient temperature: Maximum +40oC, Minimum -45oC.
3) Relative humidity: ≤90% (+25 oC).
4) Max. Outdoor wind speed 45m/s;
5) Max Ground ramp degree: ≤3°.
6) Seismic level: ≤0.3m/s2 at horizontal direction and ≤0.15m/s2 at vertical direction.
7) Installation environment: No obvious and heavy pollution, no explosive and corrosive gas and dust, with good air ventilation and no severe vibration and shock.
8) If the application environment is different from the above standard conditions, please contact for customized designs.
4.Application Scenarios
1）Grid Energy Storage: Peak shaving, frequency regulation, and voltage stabilization for utilities.
2）Renewable Integration: Solar/wind farm smoothing and curtailment reduction.
3）Microgrids: Off-grid communities, islands, and industrial sites with hybrid PV/battery systems.
4）Emergency Backup: Data centers, hospitals, and military bases requiring uninterrupted power.
